山東快速成型技術的應用不僅可以有效地提高工業生產中模具制造的效率和質量，還可以顯著降低模具的制作成本，提高生產企業的經濟效率，下面就來看看應用于這方面的表現吧。

The application of Shandong rapid prototyping technology can not only effectively improve the efficiency and quality of mold manufacturing in industrial production, but also significantly reduce the cost of mold manufacturing and improve the economic efficiency of production enterprises. Let's take a look at the performance of this application.

軟質模具

Soft mould

工作人員在使用快速成型技術來制作軟質模型時主要會使用以下方法：

When using rapid prototyping technology to make soft models, staff will mainly use the following methods:

一，硅橡膠法，通過該方法所制造的硅橡膠模具不僅有良好的彈性，同時還可以在模具上制作一些非常精美的紋路，但是該類模具的適用性不強；

1、 Silicone rubber method: the silicone rubber mold manufactured by this method not only has good elasticity, but also can make some very fine lines on the mold, but the applicability of this kind of mold is not strong;

二，樹脂法，當模具的需求量非常大時，工作人員可以使用樹脂材料作為模具的制作原材料，并且通過合理地使用快速成型技術中原型壓鑄的方式來率地完成該類型模具的批量制作；

2、 Resin method: when the demand for molds is very large, the staff can use resin materials as the raw materials for mold production, and can efficiently complete the batch production of this type of molds by reasonably using the prototype die-casting method in rapid prototyping technology;

三，金屬法，工作人員使用該方法進行模具制作時，通常以RP8d為原型，并且在此基礎上將金屬合金均勻地噴涂于模型的外表面，并且將模具的制作原材料快速地填入模具內，完成金屬模具的制作，該方法的優勢在于操作簡便、一次成型、制作周期短、耐磨性強等；

3、 Metal method: when workers use this method to make molds, rp8d is usually used as the prototype, and on this basis, the metal alloy is uniformly sprayed on the outer surface of the model, and the raw materials of the mold are quickly filled into the mold to complete the production of the metal mold. The advantages of this method are simple operation, one-time molding, short production cycle and strong wear resistance;

硬質模具

Hard die

工作人員在使用快速成型技術進行硬質模具的生產制造時，通常會使用以下方法：

When using rapid prototyping technology to produce hard molds, workers usually use the following methods:

一，電火花法，該方法主要是指工作人員將BPM作為模具的圓形，同時將EDM作為連接模具的電源，通過電火花的方式對模具進行加工制造，然后再合理地使用三維砂輪以及石墨電極的方式對該模具進行細節上的處理，終完成整個鋼模具的制作；

1、 Electrical discharge method: this method mainly refers to that the staff use BPM as the circular shape of the mold, and EDM as the power supply to connect the mold, process and manufacture the mold by means of electrical discharge, and then reasonably use three-dimensional grinding wheel and graphite electrode to process the details of the mold, and finally complete the production of the whole steel mold;

二，熔模法，該方法主要適用于鋼模具的批量制造，以RPM原型作為母版通過軟蠟熔模的方式實現鋼模具的精密復制；

2、 Investment mold method: this method is mainly applicable to the batch manufacturing of steel molds. The RPM prototype is used as the master plate to realize the precision replication of steel molds through soft wax investment mold;

三，陶瓷法，對于一些數量較少的模具批量鑄造生產企業，工作人員便可以使用陶瓷法進行模具的制作生產，依然以RPM為模板原型，將陶瓷砂漿作為模板制作的原材料，通過焙燒的方式對陶瓷砂漿進行固化處理，以此來完成模板的制作。

3、 Ceramic method: for some mold batch casting production enterprises with a small number of molds, the staff can use the ceramic method to produce molds. The rpm is still used as the template prototype, and the ceramic mortar is used as the raw material for the template production. The ceramic mortar is cured by baking to complete the template production.

快速成型技術在軟質模具和硬質模具的制作與生產中也起到了非常關鍵性的作用，如果您想更好的使用這項技術做工作，就要多來了解內容，更多事項就來我們網站http://m.xtgs.com.cn咨詢吧。

Rapid prototyping technology also plays a very important role in the manufacture and production of soft and hard molds. If you want to better use this technology to do your work, you should learn more about the content. For more information, please visit our website http://m.xtgs.com.cn Consult.
